Model | XS-FA430 |
|
Size | 43Inch |
|
Display area | 529.416*941.184mm |
|
Resolution | 1080*1920 |
|
Proportion | 9:16 |
|
Brightness | 300cd/㎡ |
|
Response time | 5ms |
|
Contrast Ratio | 3000:1 |
|
Viewing angel | 89/89/89/89(up/down/left/right) |
|
Android specs. (Optional) | ||
CPU | Rock Chip RK3288 quad-core CPU Mail-Mail – T764 | |
Memory | DDR3 2G 4G Optional | |
Storage | EMMC 8GB, 16G/32 Optional | |
Computer Specs (Optional) | ||
CPU | Intel I3/ I5/ I7, dual core processor | |
Memory | 4G DDRIII, 8G optional | |
Storage | 500G HDD or 128G SSD optional | |
External Interface | HDMI Input、VGA Input、RJ45、USB*2 | |
Speaker | 2 x 5W (8Ω) | |
Working Environment | Temperature: 0℃ ~55℃ 10%-85% Humidity: 10% – 85% | |
Input Voltage | AC 110V-240V 50/60Hz | |
Power | ≦220W / <5W (Standby) | |
Dimension | 1778*621*84.8mm |
|
Body Weight | 36.5Kg |
|
Base Weight | 8.2Kg |
|
Input Voltage | AC 110V-240V 50/60Hz |
|
Power | ≦120W |
|
55 inch
Model | XS-FA550 |
|
Size | 55Inch |
|
Display area | 680.4*1209.6mm |
|
Resolution | 1080*1920 |
|
Proportion | 9:16 |
|
Brightness | 500cd/㎡ |
|
Response Time | 5ms |
|
Contrast Ratio | 3000:1 |
|
Viewing angel | 89/89/89/89(up/down/left/right) |
|
Android specs. (Optional) | ||
CPU | Rock Chip RK3288 quad-core CPU Mail-Mail – T764 | |
Memory | DDR3 2G 4G Optional | |
Storage | EMMC 8GB, 16G/32 Optional | |
Computer Specs (Optional) | ||
CPU | Intel I3/ I5/ I7, dual core processor | |
Memory | 4G DDRIII, 8G optional | |
Storage | 500G HDD or 128G SSD optional | |
External Interface | HDMI Input、VGA Input、RJ45、USB*2 | |
Speaker | 2 x 5W (8Ω) | |
Working Environment | Temperature: 0℃ ~55℃ 10%-85% Humidity: 10% – 85% | |
Input Voltage | AC 110V-240V 50/60Hz | |
Power | ≦220W / <5W (Standby) | |
Dimension | 1904*776*84.8mm |
|
Body Weight | 54.5Kg |
|
Base Weight | 11.2Kg |
|
65inch
Model | XS-FA650 |
|
Size | 65Inch |
|
Display area | 803.52*1428.48mm |
|
Resolution | 1080*1920 |
|
Proportion | 9:16 |
|
Brightness | 450cd/㎡ |
|
Response time | 5ms |
|
Contrast Ratio | 3000:1 |
|
Viewing angel | 89/89/89/89(up/down/left/right) |
|
Android specs. (Optional) | ||
CPU | Rock Chip RK3288 quad-core CPU Mail-Mail – T764 | |
Memory | DDR3 2G 4G Optional | |
Storage | EMMC 8GB, 16G/32 Optional | |
Computer Specs (Optional) | ||
CPU | Intel I3/ I5/ I7, dual core processor | |
Memory | 4G DDRIII, 8G optional | |
Storage | 500G HDD or 128G SSD optional | |
External Interface | HDMI Input、VGA Input、RJ45、USB*2 | |
Speaker | 2 x 5W (8Ω) | |
Working Environment | Temperature: 0℃ ~55℃ 10%-85% Humidity: 10% – 85% | |
Input Voltage | AC 110V-240V 50/60Hz | |
Power | ≦220W / <5W (Standby) | |
Dimension | 2084*912*84.8mm |
|
Body Weight | 66Kg |
|
Base Weight | 13.8Kg |
|
